SYBILO Smoke Extraction Jet Fans
Designed for Effective Ventilation Inside the Fire Danger Zone
Manufacturing Features:
Centrifugal fan made of galvanised steel.
Galvanised steel sheet casing.
Strong backward impeller with self-cleaning system, made of galvanised steel sheet.
Airflows up to 9200 m³/h.
External wiring box.
Inlet protection.
Feet included.
Class H insulation, S1 continuous use and S2 emergency use, with bearing balls,
IP-55 protection, 2 speeds.
400V 4/8 poles Dalhander three phase motor.
Maximum working temperature: S1 -> -20ºC +60ºC, S2 -> 400ºC / 2h.
Suitable for Hazardous Areas
The sybilo range of centrifugal jet fans with low profile are suitable to be installed in hazardous areas. They can remove large air volumes and are commonly installed in carparks or large areas where polluted air, or smoke needs to be removed effectively.
SYBILO F400: Centrifugal long range jet fan
(Alternatively, we also offer Casals JF smoke extraction jet fans).
• Car parks
• Hazardous areas
Technical Data
The sybilo series of F400 centrifugal jet fans are paired with an ATEX certified motor offering 400ºC/2h and 300ºC/2h.
Fan Type | Voltage (V) |
Frequency (Hz) |
Input Power (kW) |
Rated Current (A) |
Speed (rpm) |
Max Temp (°C) |
IP Rating (IP) |
---|---|---|---|---|---|---|---|
GKHM 355-CIG.102.5HF IE Gen3 (IE5) | 3~ 380-480 | 50 / 60 | 2.33 | 3.7 at 400V | 3120 | 40 | IP54 |
GKHM 400-CIG.114.6FF IE Gen3 (IE5) | 3~ 380-480 | 50 / 60 | 4.48 | 7 at 400V | 3170 | 40 | IP54 |
GKHM 450-CIG.128.6IF IE Gen3 (IE4) | 3~ 380-480 | 50 / 60 | 5.9 | 9.05 at 400V | 2950 | 40 | IP54 |
GKHM 500-CIG.143.6NA IE Gen3+ (IE4) | 3~ 380-480 | 50 / 60 | 7.48 | 11.4 at 400V | 2625 | 40 | IP54 |
GKHM 560-CIG.160.6NA IE Gen3+ (IE4) | 3~ 380-480 | 50 / 60 | 6.85 | 10.7 at 400V | 2125 | 40 | IP54 |
GKHM 630-CIG.180.6NA IE Gen3+ (IE4) | 3~ 380-480 | 50 / 60 | 5.1 | 7.88 at 400V | 1580 | 40 | IP54 |
